Level converter with RS-232 interface, MPW32-RS-232

The level converter MPW32 RS-232 offers high flexibility and easy
integration in one device.
The MPW32 RS-232 level converter is equipped with an RS-232 interface.
The high M-Bus voltage of 38V makes it possible to operate large M-Bus
networks safely.
With M-Bus transmission rates of 300 to 38400 baud, these level
converters are also suitable for fast M-Bus devices.
The device can be used in applications ranging from mechanical
engineering and industrial automation to home and building automation
with standardised communication.


Zusätzliche Informationen

Gewicht 0,185 kg
Größe 7 × 9 × 6,4 cm


Power supply

24 Vdc +/- 20%, 24 Vac +/- 5%

Internal current

85 mA at 24Vdc



Operating temperature

-10 – 50°C

M-Bus voltage

38 V

M-Bus current

48 mA (32 standard loads à 1,5 mA)

Over-current threshold

> 63 mA


1 x RS-232
