Smart Manager pro 32 GB eMMC Flash

Linux™ Embedded PC Controller

  • Broadcom® BCM 2837 (64-bit) Processor 1.2GHz
  • 32GB eMMC flash memory
  • 1GB memory
  • Display (freely programmable)
  • Touch button surface capacitive (freely programmable)
  • 2x RJ45 FastEthernet
  • 4x USB 2.0
  • HDMI V1.3a output
  • 1x RS-485 isolated
  • 1x RS-485/232 isolated
  • expansion bus

32 GB flash memory, display, touch

Interface overview :

  • 1 x HDMI 1.3a
  • 2 x 10/100 MBit Fast Ethernet
  • 4 x USB 2.0 A

bottom view:







Artikelnummer: 95438 Kategorien: ,

Zusätzliche Informationen

Gewicht 0,218 kg
Größe 8,97 × 10,8 × 6,07 cm
EAN/GTIN

4260541720225

Protection

IP20

Power supply

min. 12 V – max. 30 V DC

Power consumption

25 Watt (inkl. 6 x 500 mA at each USB-Port)

Operational temperature

-40°C bis +55°C

Storage temperature

-40°C to +65C°

Interfaces

6 x USB 2.0 A, 1 x Micro-USB 1 x HDMI V1.3a 2 x RJ45 (Ethernet) 10/100 Mbit/s 1 x RS-485, isolated, individually terminable 1 x RS-485 or RS-232 switchable by software 1 x extensionsbus with 3 x UART, 1 x I2C

Processor

1,2 GHz, Quad-Core 64-bit

RAM

1 GByte

Flash

8 GByte

Certificates

IEC 61000-6-2, EN55032m EN55024

Buffer timeRTC

min. 24 hours

Optical displaxs/keys

2 status LEDs freely programmable, 2 Keys freely programmable

Operating system

Debian Linux
